型号 | 8inch | 10inch | 12inch | 14inch | 18inch | 24inch | 26inch |
Solid production | 80m³/h | 120m³/h | 210m³/h | 330m³/h | 600m³/h | 800m³/h | 1200m³/h |
Hourly water flow rate | 500m³/h | 800m³/h | 1400m³/h | 2200m³/h | 3000m³/h | 4000m³/h | 6000m³/h |
Dig depth(Support customization) | 1-6m | 1-6m | 1-15m | 2-15m | 2-20m | 2-20m | 2-20m |
Conveying distance | 500m | 1000m | 1500m | 2000m | 3000m | 3000m | 3000m |
Installed power(WeiChai Engine) | 250kw | 350kw | 476kw | 989kw | 1319kw | 1728kw | 2499kw |
Oil consumption | 30L/h | 50L/h | 70L/h | 140L/h | 190L/h | 250L/h | 370L/h |
Hull size
| 11.8*3.6*1.3m | 13*4.2*1.5m | 18*4.2*1.5m | 29*7*1.8m | 29*7.5*2m | 33*7.5*2m | 44*9*2.5m |
Dredging depth
| 6m | 6m | 10m | 15m | 15m | 15m | 18m |
Quantity of cubic meters | / | / | / | 660 cubic meters | 710 cubic meters | 900 cubic meters | 1400 cubic meters |
Mode of transport | Two 40 foot containers | Two 40 foot containers | Three 40 foot containers | Bulk carrier transportation | Bulk carrier transportation | Bulk carrier transportation | Bulk carrier transportation |
Remark | 1.The greater the dredging depth, the longer the hull of the dredger.
2.The hull dimensions of the dredger indicating its current dredging capacity.
3.The brand of the engine can choose Weichai or Cummins. |
|
|
Company company are based on scientific innovation, gravity separation technology as the core, set up thagold re-election, institute of technology, and with the Shandong gold institute, ChangChun gold researchinstitute, Shenyang institute of gold, Sichuan gold institute ect .we are recommended as placer gold machingcompany by Shandong institute .Company's gravity gold machines won seven patents and we passed thelS09001 quality system certification.
